104指考數學乙選填第9題詳解

📅 104 年 📝 指考數學乙 第 9 題 題型:選填 課綱:99課綱

答案與本題考點

答案:12

本題考點:向量內積、直角三角形三角比、三角函數、平面向量

題目

如圖,長方形 $ABCD$ 中,$\angle CAB = 30^\circ$,若 $\overset{\large\rightharpoonup}{AC} \cdot \overset{\large\rightharpoonup}{AD} = \left\|\overset{\large\rightharpoonup}{AC}\right\|$,則 $\overset{\large\rightharpoonup}{AC} \cdot \overset{\large\rightharpoonup}{AB} = $ ____。
104_07B_q09_fig01
向量內積直角三角形三角比三角函數平面向量

答案

答案

12

詳解

詳解

SOLUTION

跟著解題方向,一步一步看懂。

另解
用三角函數表示各邊,再用內積定義。 設 $\left|\overset{\large\rightharpoonup}{AC}\right|=r$。在直角 $\triangle ACD$ 中,$\angle ACD=\angle CAB=30^\circ$,所以 $$\left|\overset{\large\rightharpoonup}{AD}\right|=r\sin 30^\circ=\dfrac{r}{2},\quad \left|\overset{\large\rightharpoonup}{AB}\right|=\overline{DC}=r\cos 30^\circ=\dfrac{\sqrt{3}}{2}r$$ 由內積定義,$\angle CAD=60^\circ$, $$\begin{aligned} &\overset{\large\rightharpoonup}{AC}\cdot\overset{\large\rightharpoonup}{AD}=r\cdot\dfrac{r}{2}\cdot\cos 60^\circ=\dfrac{r^2}{4}=r\\ \Rightarrow\ &r=4 \end{aligned}$$ 所以 $$\overset{\large\rightharpoonup}{AC}\cdot\overset{\large\rightharpoonup}{AB}=r\cdot\dfrac{\sqrt{3}}{2}r\cdot\cos 30^\circ=\dfrac{3}{4}r^2=12$$
另解
把 $\overset{\large\rightharpoonup}{AC}$ 分解成兩鄰邊向量。 在長方形 $ABCD$ 中,$\angle CAB = 30^\circ$,且 $\overline{AB} \perp \overline{AD}$。將向量分解為 $$\overset{\large\rightharpoonup}{AC} = \overset{\large\rightharpoonup}{AB} + \overset{\large\rightharpoonup}{AD}$$ 在直角三角形 $ABC$ 中,因為長方形中 $\overline{BC} = \overline{AD}$,所以 $$\tan 30^\circ = \dfrac{\overline{BC}}{\overline{AB}} = \dfrac{\overline{AD}}{\overline{AB}}$$ 設 $\overline{AB} = x$,則 $$\overline{AD} = x \tan 30^\circ = \dfrac{x}{\sqrt{3}}$$ $$\left|\overset{\large\rightharpoonup}{AC}\right| = \sqrt{x^2 + \dfrac{x^2}{3}} = \dfrac{2x}{\sqrt{3}}$$ $$\overset{\large\rightharpoonup}{AC} \cdot \overset{\large\rightharpoonup}{AD} = \left(\overset{\large\rightharpoonup}{AB} + \overset{\large\rightharpoonup}{AD}\right) \cdot \overset{\large\rightharpoonup}{AD} = \overset{\large\rightharpoonup}{AB} \cdot \overset{\large\rightharpoonup}{AD} + \left|\overset{\large\rightharpoonup}{AD}\right|^2$$ 因為 $\overset{\large\rightharpoonup}{AB} \perp \overset{\large\rightharpoonup}{AD}$,所以 $\overset{\large\rightharpoonup}{AB} \cdot \overset{\large\rightharpoonup}{AD} = 0$,因此 $$\overset{\large\rightharpoonup}{AC} \cdot \overset{\large\rightharpoonup}{AD} = \left|\overset{\large\rightharpoonup}{AD}\right|^2 = \dfrac{x^2}{3}$$ 又已知 $\overset{\large\rightharpoonup}{AC} \cdot \overset{\large\rightharpoonup}{AD} = \left|\overset{\large\rightharpoonup}{AC}\right| = \dfrac{2x}{\sqrt{3}}$,所以 $$\dfrac{x^2}{3} = \dfrac{2x}{\sqrt{3}}$$ $$x^2 = 2\sqrt{3}x$$ 因為 $x$ 是邊長,$x > 0$,得 $x = 2\sqrt{3}$。 同樣利用分解式,且 $\overset{\large\rightharpoonup}{AD} \cdot \overset{\large\rightharpoonup}{AB} = 0$: $$\overset{\large\rightharpoonup}{AC} \cdot \overset{\large\rightharpoonup}{AB} = \left(\overset{\large\rightharpoonup}{AB} + \overset{\large\rightharpoonup}{AD}\right) \cdot \overset{\large\rightharpoonup}{AB} = \left|\overset{\large\rightharpoonup}{AB}\right|^2 + 0 = x^2 = 12$$ 故 $\overset{\large\rightharpoonup}{AC} \cdot \overset{\large\rightharpoonup}{AB} = 12$。

題目來源:民國104年指考數學乙 第9題(來源PDF第5頁)
